Soundproof Curtains for Industrial Noise Control - Dual Sided SCC-10 and SCC-11

Steel Guard Safety's Sound Shield Industrial Noise Control Curtains features easy hanging grommets on top and hook and loop velcro attachments on the sides to modularly make any width. Mount them as stationary Sound Barriers around Industrial Equipment or Machines, or add dual curtain track hardware (sold separately) to make a moveable barrier.

The Sound Shield SCC-10 and SCC-11 Combination Sound Blanket is a sound barrier curtain panel used to block and absorb sound for interior applications. The sound absorbing curtains have a mass loaded vinyl 1 lb / sq ft or 2 lb sq / ft interior encapsulated with a 1" quilted fiberglass batting on front and 1" on the back, allowing for both sound absorption on and sound attenuation on both sides.

Generally used to temper and block noise in industrial environments, these curtain-blankets are commonly used as separator walls or divider partitions and to line the perimeter of an interior wall. SCC-10 & SCC-11 Sound Shield Soundproof Curtains are Class 1 fire-rated and are a double duty sound blanket in that they work for both absorbing and blocking sound.

CALL FOR CUSTOM SIZES

Sound Curtain Panels

Sound blanket panels in 4′ widths with 8', 9' and 10' heights or custom lengths as required (Call)
#4 Grommets along top hem
Mating Velcro® on vertical edges (This allows the blankets to overlap and create a sound seal.)
Track Hardware Kit Option - Includes Qty 1 - 4 ft Straight Track, Qty 5 Nylon Rollers, Qty 2-End Stops, and Qty 2-Universal Mount In-line Connectors (for Threaded Rod, Chain, or Wall Mounting)
Track Kits Connect Modularly for Whatever Length needed.
Sound Curtain Meets ASTM E-84 for Indoor Use
Other Configurations Available (Call)

SOUND ABSORPTION (HZ) PER ASTM C423

Model Number	125	250	500	1000	2000	4000	NRC
SCC-10 & SCC-11	.18	.62	.89	.84	.60	.45	.75

SOUND TRANSMISSION LOSS (HZ) PER ASTM E90 & E413

Model Number	Barrier	125	250	500	1000	2000	4000	STC
SCC-10	1 lb.	12	16	27	40	44	43	29
SSC-11	2 lb.	19	22	28	40	56	61	33

Ships 7 - 10 Business Days

	SCC-10	SCC-11 ,
SIZES W x H	4 ft x 8 ft, 4 ft x 9 ft, 4 ft x 10 ft, or Custom	4 ft x 8 ft, 4 ft x 9 ft, 4 ft x 10 ft, or Custom
COLOR	Gray	Gray
MATERIAL	1 in Quilted Fiberglass on Front plus 1 lb / sq. ft. Mass Loaded Vinyl Interior plus 1 in Quilted Fiberglass Back.	1 in Quilted Fiberglass on Front plus 2 lb / sq. ft. Mass Loaded Vinyl Interior plus 1 in Quilted Fiberglass Back.
GROMMETS	1 ft O. C. on Top (#4)	1 ft O. C. on Top (#4)
VELCRO	2 in Hook & Loop Front & Back on Sides	2 in Hook & Loop Front & Back on Sides
NOISE RED. COEFFICIANT (NRC)	.75	.75
SOUND TRANSMISSION LOSS (STC)	29	33
WITHSTAND TEMP.	180 Degrees F	180 Degrees F
CHEMICAL RESISTANCE	Water & Mildew	Water & Mildew
WEIGHT	1.50 lb / Sq. Ft	2.50 lb / Sq. Ft
FLAME RESISTANCE	ASTM E-84 Class I	ASTM E-84 Class I

Industrial Soundproof Curtain Extended Info
